| Application | Temperature detection inside the pellet furnace |
| Material | 304 stainless steel |
| Sensor Head Dimension | Head diameter φ4.7 / φ5 |
| Operating Temperature Range | -50ºC ~ +450ºC |
| Accuracy | PT100, PT200, PT1000 |
| Response Time | ~11s (In the air) |
| Thermal Time Constant | ~11s (In the air) |
| Withstand Voltage | AC1500V, AC1200V |
| Insulation Resistance | DC500V >100MΩ |
| Resistance Value | PT100, PT200, PT1000 (customizable to customer requirements) |
| B Value | TCR=3850ppm/K (customizable to customer requirements) |
