FT-34.7G-B2
DGEGT
Basic Info.
| Model NO. | FT-34.7G-B2 | Material | Metal |
| Certification | RoHS | Customized | Custom-made |
| Connecting Wires | As required | Maximum Input Voltage | 6-12VDC Max. |
| Transport Package | Natural Export Packing | Specification | Piezo Buzzer |
| Trademark | DGEGT | Origin | Dongguan, China |
| HS Code | 8531801001 | Production Capacity | 10000000Pieces /Year |
Product Description
| Sound Press Level (SPL) | ≥85dB |
| Main Electrostatic Capacitance | 32000~45000pF (at 1KHz/1V) |
| Feedback Electrostatic Capacity | 3200~4900pF (at 1KHz/1V) |
| Resonance Impedance | ≤120Ω |
| Insulation Resistance | ≥100MΩ (at50V DC) |
| Resonance Frequency | 3.2±0.25KHz |
| Metal Plate Diameter | Φ34.7±0.1 mm |
| Ceramic Disc Diameter | Φ25.0±0.3 mm |
| Total Thickness | 0.55~0.570 (for reference) |
