FT-27T-3.2 A1-C35
DGEGT
Basic Info.
| Model NO. | FT-27T-3.2 A1-C35 | Material | Metal |
| Certification | RoHS | Customized | Custom-made |
| Connecting Wires | As required | Maximum Input Voltage | 6-12VDC Max. |
| Transport Package | Natural Export Packing | Specification | Piezo Buzzer |
| Trademark | DGEGT | Origin | Dongguan, China |
| HS Code | 8531801001 | Production Capacity | 10000000Pieces /Year |
Product Description
| Sound Press Level (SPL) | ≥85dB |
| Free Capacitance (RF) | 36000±20% (at 1KHZ/1V) |
| Feedback Electrostatic Capacity | 3600±20% (at 1KHZ/1V) |
| Equivalent Resistance | <300Ω |
| Insulation Resistance | ≥100MΩ (at50V DC) |
| Resonance Frequency | 3.2±0.3KHz |
| Metal Plate Diameter | Φ27.0±0.1 mm |
| Piezoelectric Plate Diameter | Φ20.0±0.3 mm |
| Total Thickness | 0.37±0.05 mm |
